PORTING TEMPLATES for MAZDA ROTARY ENGINES allow you to undertake your own intake and exhaust porting efforts on all model years of the MAZDA ROTARY engine.



OPTIONS for porting :



· RX7 STREET PORT 6 PORT INTAKE PORTING

(contains PORTING for FRONT, CENTRE and REAR HOUSINGS)



· RX7 86-99 FULL BRIDGE PORTING



· RX7 TURBO 87-95 HALF BRIDGE PORTING

(contains PORTING for CENTRE and END HOUSINGS)



· RX7 TURBO 87-95 STREET PORTING

(contains PORTING for FRONT, CENTRE and REAR HOUSINGS)



· MAZDA 12A, 13B, J-BRIDGE 4-PORT INTAKE PORTING

(12A or 13B rotary engine (NOT SUITABLE FOR 13B 6-port)



· MAZDA 12A, 13B, STREET 4-PORT INTAKE PORTING

(12A or 13B rotary engine (NOT SUITABLE FOR 13B 6-port)



· MAZDA 12A EXHAUST RACE PORTING



· MAZDA 12A EXHAUST STREET PORTING



· MAZDA 13B EXHAUST RACE PORTING

(ALL 74-95 Turbo and Non-Turbo)



· MAZDA 13B EXHAUST STREET PORTING

(ALL 74-95 Turbo and Non-Turbo)



· RX8 4-PORT INTAKE HALF BRIDGE PORTING



· RX8 6-PORT INTAKE FULL BRIDGE PORTING



· RX8 4-PORT INTAKE BIG HALF BRIDGE PORTING



· RX8 RENESIS ALL STREET INTAKE PORTING





The actual port shapes are traced on thin sheets of aluminum which you must first cut out, testing your ability to use a die grinder effectively before attempting to port an expensive engine component.



The finished template is held in place and the porting shape is then traced onto each housing.



Included with the porting templates are detailed instructions and advice to guide you through your porting efforts.



Limited clearance on the side housings creates additional challenges when porting these housings, our instructions provide detailed photos of the most critical areas of concern.
